UVA LED Panel (2×4)
ThinkLite UVA LED Technology has been specially designed to provide ambient type lighting to match any application or environment, while emitting safe and optimal amounts of UVA to activate PURETi® on all surfaces.
The LED Panels are extremely easy to install with industry leading efficiency. The panel can be used to replace a 2×4 fluorescent or LED fixture. This fixture is recommended for applications where existing fixtures have an integrated lens that prevent the UVA radiation from effectively passing through to successfully activate the PURETi.
- Physical appearance looks identical to industry standards
- Ambient light levels available in all colors, including 2100K to 6000K
- Improves Indoor Air Quality by up to 50%
- Vibration and impact resistant
- Longer lifespan (70,000 hours) / 10-year warranty
- Instant ON/OFF
- Intelligent controls options available:
-
- Regulate UVA intensity based on application
- Set schedules, timers, grouping and routines
- Integrate automated light controls and behavior based on air quality data measured by TL Flair IAQ Monitors
- Energy consumption tracking and reporting
- Control fixture using the ThinkLite Pro iOS / Android App
| Input Voltage: | Input Frequency: | Lumen Efficacy: | Visible Factor: |
|---|---|---|---|
| 120V-277V | 50Hz – 60Hz | 160 LM/W | 1.5x |
| Power Factor: | Working Environment: | Wavelength/Kelvin Options: | Mounting types: |
| >0.99 | Indoor | 370nm UVA+(2100K to 7000K) | Recessed |
| Dimming: | Operating Temperature: | Mercury: | |
| 0-10V | -30°F to 170°F | None |
| 25W: 3,750 Lumens | 32W: 4,800 Lumens | - | - |
Wiring Guide
