1×4 LED Retrofit Kit
ThinkLites LED Retrofit Kit is the most efficient alternative to ALL types of linear fluorescent fixtures, including those with T12, T8, and T5 lamps. With an industry leading efficacy of 180 Lumens per watt, this solution can easily maintain or increase light levels while saving 70% in energy consumption. The simple design ensures the quickest installation time in the industry and includes a unique feature that ensures a fluorescent lamp cannot be re-inserted back into the same fixture; commonly referred to as snap back.
- Proprietary driverless LED technology: no external driver
- Reduced energy consumption by 70%
- Simple design for quick and easy installation
- Dimmable option (TRIAC & 0-10V) versions available
- Earthquake resistant design
- Can be used with standard troffers/fixtures for new construction
- No harmful UV rays
- 7 year warranty
- Longer lifespan (70,000 hours)
- LED light Source also available with 360 Output in select wattages
|Input Voltage:||Input Frequency:||Lumen Efficacy:||Visible Factor:|
|85V - 277V||50Hz - 60Hz||180 LM/W||1.5x|
|Power Factor:||Working Environment:||Kelvin Options:||Beam Angles/Spread:|
|>0.99||Indoor / Outdoor||2100K - 7000K||180° - 270°|
|CRI:||Lumen Depreciation:||Operating Temperature:||Lens Cover:|
|93+||5% at 70,000 hours||-30°F to 170°F||Clear / Opaque|
|14W: 2,520 Lumens||24W: 4,320 Lumens|
